Technical support:
Random provide equipment drawings(CAD),the installation drawing,the product quality certificate,installation and operating instructions,etc.
Capacity(L) | Motor power(kw) | Tank body height(mm) | Tank body diameter(mm) | Mixer speed(r/min) | Working pressure(mpa) | Working temperature | Accessories |
300 | 0.55 | 600 | 800 | 36r/min(0~120r/min is optional) |
≤0.09Mpa(atmospheric pressure) |
<160℃ |
Thermometer safely valve pressure gauge |
400 | 0.55 | 800 | 800 |
36r/min(0~120r/min is optional) |
≤0.09Mpa(atmospheric pressure) |
<160℃ |
Thermometer safely valve pressure gauge |
500 | 0.75 | 900 | 900 |
36r/min(0~120r/min is optional) |
≤0.09Mpa(atmospheric pressure) |
<160℃ |
Thermometer safely valve pressure gauge |
800 | 0.75 | 1000 | 1000 |
36r/min(0~120r/min is optional) |
≤0.09Mpa(atmospheric pressure) |
<160℃ |
Thermometer safely valve pressure gauge |
1000 | 0.75 | 1220 | 1000 |
36r/min(0~120r/min is optional) |
≤0.09Mpa(atmospheric pressure) |
<160℃ |
Thermometer safely valve pressure gauge |
1500 | 1.5 | 1220 | 1200 |
36r/min(0~120r/min is optional) |
≤0.09Mpa(atmospheric pressure) |
<160℃ |
Thermometer safely valve pressure gauge |
2000 | 2.2 | 1500 | 1300 |
36r/min(0~120r/min is optional) |
≤0.09Mpa(atmospheric pressure) |
<160℃ |
Thermometer safely valve pressure gauge |
3000 | 3 | 1500 | 1600 |
36r/min(0~120r/min is optional) |
≤0.09Mpa(atmospheric pressure) |
<160℃ |
Thermometer safely valve pressure gauge |
