Application:

It is suitable for different shape packaging of Alu / PVC , Paper/Alu and Alu /Alu for capsule, tablet, candy, honey shape pills, disposable syringes and so on in industries of pharmaceutical, foodstuff, health product , medical instruments and etc.

Product introductions:

The machine is new innovating designed by our machine which is widely for packaging of medicine, which of function are reached to the advanced level of China. It is used for tablet, capsule, pill, honey pill, candy, liquid, paste, disposable syringe in regular and irregular shaped Alu/PVC, Alu/Alu or Paper /Alu in the field of pharmaceutical, health product, foodstuff, cosmetic , medical instrument and etc.

Technical Specifications:

Punches Frequency: 10/40times/min

Production capacity:2400-9600pcs/hour

Max. Forming area and depth : 240x140x26mm

(Standard plate size: 240x140x14mm)

Stroke travel range: 40-140mm

Standard plate size: 80x57mm( designed as per user’s requirement)

Air pressure: 0.4-0.6Mpa

Air compressed required: ≥0.3m3/min

Total power supply: 380V/220V 50Hz 8.5kw

Main motor: 2.2KW

PVC hard film: 0.15-0.5×250 mm

PTP Aluminum film

Dialysis paper: 50-100g×250mm

Mould cooling: Tap water or recycling water

Overall dimension: 3250×710×1700mm(L×W×H)

Weight: 1400kg
