Type of drive |
Mechanical drive (CAM gear lever full mechanical mode) |
Form of measurement |
Bowl feeding, combination scale, etc. (optional) |
Applicable material |
Big leaf wool belly, nuts fried goods, big red dates, puffed class, bags of big bags of products, etc |
Work process |
① On the bag ② empty ③ open the bag, bag ④ a ⑤ reserve ⑥ reserve ⑦ seal one ⑧ seal two |
Sealing type |
One sealing, two sealing plastic, to ensure that the sealing is beautiful and firm |
Packaging speed |
10 bags -50 bags/min (depending on the product and the amount) |
Packing bag material |
Self-supporting bag, zipper bag, four-side sealing bag, three-side sealing bag, paper bag (surface covered paper), etc |
Packing bag size |
Width 120mm-260mm ,Length 100-400mm |
Total power |
Host power ≈4.5KW |
Air consumption |
0.6m³/min |
Driving source |
Three-phase 380V 50Hz (non-national standard three-phase 380V 60Hz) |
Machine size |
1800mm*1440mm*1310mm(L*W*H)(Products conveyor not included) |
Machine weight |
2T(main machine) |
Operating environment |
Room temperature 10℃~40℃ 30~90%RH, no dew, no corrosive gas, no dust and other harsh environment |
