Main Technical Data
Product No. |
HLSG-100 |
Total Volume (l) |
100 |
Feeding Quantity |
15-40 |
Max. Inside Diameter (mm) |
640 |
Rotational Speed of Stiming Paddle (r/min) |
20-300 |
Power of Motor (kw) |
11 |
Rotational Speed of Cutter (r/min) |
300-3000 |
Power of Motor (kw) |
4 |
Overall Size (mm) |
2200*870*1560 |
Weight (kg) |
1540 |
Configuration List
Series No. |
Name |
Type |
Qty |
Manufacturer |
1 |
Frequency Converter |
VFD075B43A |
1 |
Delta |
2 |
Frequency Converter |
VFD037B43A |
1 |
Delta |
3 |
Touch Screen |
TK6070 |
1 |
Weilun |
4 |
PLC |
CPU224, 20W |
1 |
Delta |
5 |
Speed Adjuster |
EM232, 10W |
1 |
Delta |
6 |
Breaker |
DZ47-63 63 32A |
1 |
Zhengtai |
7 |
Single-pole Breaker |
DZ47-63 63 32A |
1 |
Zhengtai |
8 |
Power Supply |
S-50-24 |
1 |
Delta |
9 |
Small Relay |
HH52P, 5A, 220V |
3 |
Zhengtai |
10 |
Emergency Stop Switch |
LA19Y 10A |
1 |
Schneider |
11 |
Temperature Controller |
SW-C4 |
1 |
Shanghai |
12 |
Thermocouple |
K Type |
1 |
Zhejiang |
13 |
Motor |
Y160M-6, 7.5kw |
1 |
Shanghai Dedong |
14 |
Motor |
Y100L-2.3kw |
1 |
Shanghai Dedong |
15 |
Solenoid Valve |
ZW-40-10, 220V |
3 |
Zhejiang |
16 |
Pressure Gauge |
1.6mpa |
1 |
Zhejiang |
17 |
Proximity Switch |
JIZ-D4NK 5A |
1 |
Zhejiang |
18 |
Buzzer |
AC220V |
1 |
Zhengtai |
19 |
Solenoid Valve |
4V210-08 |
1 |
AirTac |
20 |
Solenoid Valve |
4V230C-08 |
1 |
AirTac |
